Turbo Schematic LEVO SL - Dropper Cable Routing

27
1
2
6.2.4. DROPPER CABLE
DROPPER POST
 1. Route the dropper cable up through the integrated cable guide tube inside the down tube until it exits the ICR
port on the drive side of the head tube.
 2. Guide the other end of the dropper housing up into the seat tube, until it exits the seat tube.Ensure the dropper
post cable housing exits past the top of the frame to guarantee access when installing the dropper post.
Make sure enough cabling is exiting the frame to properly install the dropper post.
Once bicycle assembly is complete, install the dropper post according to the manufacturer’s specifications.
