Rear shock hardware
kit - Carbon
S210500021
BLT KIT, MY22 LEVO SL (GEN.2) CARBON, REAR SHOCK MOUNTING BOLT KIT 1
Rear shock mounting bolt
—Carbon extension
M8 x 25 mm bolt SCR,CUST,M8X1.25 X 26,302 SST,SIL 1
Rear shock mounting bolt
—Alloy extension
M8 x 28 mm bolt SCR,CUST,M8X1.25 X 28,TI,LCK 1
Rear shock mounting
washer
8.2 Mm id x 13 mm od x 0.5 Mm thick washer WSHR,FLAT,M8,8.2 ID X 13 OD X 0.5 THICK,304 SST 1
Forward shock mounting
axle
Fsm,mtb,xc fsr h1, axle AXLE,FSM,MTB,XC FSR H1 1
Forward shock mounting
screw
M5 x 11 mm bolt SCR,CUST2,M5X0.8 X 11,SST,BLK,LCK 1
S214200059
SUB MY22 LEVO SL CARBON, GEO ADJUST DROPOUT PIVOT SPACERS 1
Horst link outer flip chip Pivot spacer, geo adj, 6.0 Mm id, flip chip SPCR,DO PIVOT SPACER,GEO ADJ,6.0 ID,FLAT,ALY 2
Horst link inner flip chip Pivot spacer, geo adj 6 mm x 1 mm, flip chip SPCR,DO PIVOT,GEO ADJ,M6 X 1,ALY 2
Horst pivot bolt M6 x 32.5 mm x 1.0 mm p, bolt SCR,CUST,M6X1.0 X 32.5,STL,BLK 2
Horst link outer spacer 12 mm id x 21 mm od x 2.5 mm w, spacer HORST PIVOT OUTER SPACER ASSY 12X21X2.5 4
8.2. SERVICE PARTS: CARBON FRAME
PART NAME
SERVICE
PART
NUMBER
PART SPECIFICATION PART DESCRIPTION QTY
Levo SL suspension bolt kit -
Carbon
S210500019
SUSPENSION BOLT KIT MY22 LEVO SL CARBON 1
Forward shock mounting axle Fsm,mtb,xc fsr h1, axle AXLE,FSM,MTB,XC FSR H1 1
Forward shock mounting bolt M5 x 11 mm x 0.8 mm p, bolt SCR,CUST2,M5X0.8 X 11,SST,BLK,LCK 1
Rear shock mounting bolt - Alloy
extension
M8 x 26 mm x 1.25 mm p, bolt SCR,CUST,M8X1.25 X 26,302 SST,SIL 1
Rear shock mounting bolt - Carbon
extension
M8 x 28 mm x 1.25 mm p, bolt SCR,CUST,M8X1.25 X 28,TI,LCK 1
Rear shock mounting washer 8.3 mm id x 13 mm od x 0,5 mm thick, washer WSHR,FLAT,M8,8.3IDX13ODX0.5THK,304SST 2
Main pivot bolt DS M12 mm x 20 mm x 1.0 mm p, left hand, bolt SCR ASSY,CUST,M12X1.0 X 20,FSR2 LH,7075,BLK 1
Main pivot bolt NDS M12 mm x 20 mm x 1.0 mm p, bolt SCR ASSY,CUST,M12X1.0 X 20,FSR2,7075,BLK 1
Link at extension bolt M12 mm x 14 mm x 1 mm p, bolt SCR ASSY,M12 X 1.0 X 14,FSR 2
Link at seat tube pivot bolt M12 mm x 17 x 1.0 mm p, bolt SCR ASSY,M12 X 1.0 X 17,21MM HEAD,FSR 2
Forward shock mounting bolt M5 x 11 mm x 0.8 mm p, bolt SCR,CUST2,M5X0.8 X 11,SST,BLK,LCK 1
Link at seatstay bolt - Carbon M12 x 27 mm x 1.0 mm p, bolt SCR,SHLDR, CUST,M12X1.0 Ø12 X 27,7075,BLK 2
Main pivot / link at seat tube / link
at seatstay spacers
12.1 mm id x 19.5 mm od x 3 mm w, spacer SPCR,12.1 ID X 19.5 OD X 3 W,FSR,AL7075-T6 8
Horst pivot bolt M6 x 32.5 mm x 1.0 mm p, bolt SCR,CUST,M6X1.0 X 32.5,STL,BLK 2
Horst link outer flip chip Do pivot spacer,geo adj,6.0 Id, flip chip SPCR,DO PIVOT SPACER,GEO ADJ,6.0 ID,FLAT,ALY 2
Horst link inner flip chip
Do pivot spacer,geo adj 6 mm x 1 mm, flip
chip
SPCR,DO PIVOT,GEO ADJ,M6 X 1,ALY 2
Horst link inner spacer
6 mm id x 16 mm od x 16 mm w, stepped
spacer
SPCR,STEP,6MM ID X 16MM OD X 16MM W,7075-T6 2
Horst link outer spacer 12 mm id x 21 mm od x 2.5 mm w, spacer HORST PIVOT OUTER SPACER ASSY 12X21X2.5 4
Suspension bearing kit - Carbon
S210600003
BRG MY22 LEVO SL CARBON SUSPENSION BEARING KIT 1
Suspension bearings 12 mm id x 21 mm od x 5 mm w, ball bearing BRG,BALL,12MM ID X 21MM OD X 5MM W,DBL SLD 10
Main pivot bearing 12 mm id x 24 mm od x 6 mm w, ball bearing BRG,BALL,12MM ID X 24MM OD X 6MM W,DBL SLD 2
Chain guide S231200005 Chainguide (Carbon ver.2)
CHG LEVO SL (GEN.2), CARBON FRM, CHAIN GUIDE,
MOTOR BOLT MOUNTED, 32-34T
1
