Turbo Schematic LEVO SL - Service Parts Information; Shared Service Parts List

59
8. SERVICE PARTS
8.1. SERVICE PARTS: SHARED PARTS
PART NAME
SERVICE
PART
NUMBER
PART SPECIFICATION PART DESCRIPTION QTY
Sram universal derailleur
hanger
S202600002 SRAM UDH
HGR SRAM AC UDH DERAILLEUR HANGER AL BLACK
(00.7918.089.000)
1
Rear thru-axle S220200002
Axle diameter 12 mm,rear hub 148 mm, total
length 174.5 mm
Axl Ta, 12x148mm, 174.5mm Length, Bolt On 6mm, Blk
1
Seat post clamp S214700007 Seat post clamp
STC SPL-SC02-386A-02,38.6MM EXTRUDED,7075-T73, BLACK
ZINC BOLT,CLAMP TYPE,W/SKIRT FOR SHIMMED FRAMES
1
Seat post shim S174900001 Seat post shim STP SEATPOST SHIM 34.9OD - 30.9ID 1
6 Bolt rotor mount speed
sensor magnet assembly
S194200016 Speed sensor magnet SUB MY19 LEVO FSR SPEEDSENSOR-MAGNET KIT 1
Range extender charger
cable
98920-5660 Re: charger cable CA,PLW CHARGER Y-CABLE 1
Range extender 98920-5640 Range extender BTRY,PLW,EXTERNAL,160WH,SBC-B16, X3-168 1
Battery charger Sbc-co6 charger
CHARGER KIT, MODIARY, SBC-C06, TURBO CHARGER, 54.6V3A,
W/AC CORD, W/MANUAL, W/SOFT CASE
1
Internal battery S196800015 Battery
ELE BATTERY SL SYSTEM, INTEGRATED, 320WH, SBC-B15,
W/O BOLTS
1
Range extender rubber
band
S209900007 Rubber band MSC RANGE EXTENDER BAND, TUBE 1
Charge port door S209900023 Charger socket MSC SL SELF OPENING CHARGE PORT KIT 1
Main harness S196800021 Main harness cable ELE WIRING, SL SYSTEM. MAIN HARNESS MOTOR-BATTERY-TCU 1
Range extender cable 98922-5665 145 mm RE-CABLE 145MM 1
MasterMind tcu S216800020 MasterMind TCU ELE TURBO CONNECT UNIT 2 1
Tcu bolt S210500022 M4 x 10 mm x 0.7 mm p BLT TCU,M4X0.7X10,TORX,LP,AL 7075 T73,BLK 1
Trail remote S216800019 Bar mounted remote ELE TRAIL REMOTE 2 1
Headset kit S182500005 Complete headset
HDS NO.42/ACB/S/F/N 46CONE SPACER,AL COMPRS
RING,UP1.125/LOW1.5 CRMO 45,AL CROWN RACE,ANO MATT
BLK
1
Adjustable geometry
headset cups
S212500015 Upper zero offset cup / Upper +/-1° offset cup
HDS SUB, MY22 LEVO HEADSET CUPS KIT, W/ 0-DEG AND
+/-1-DEG CUPS
2
Headset cap S212500012 10 mm HDS HEADSET CAP TH H2487A 10MM 1
Headset cap S212500013 20 mm HDS HEADSET CAP TH H2487B 20MM 1
Front wheel rim S193700004 29"
RIM RIM-665 FOR MY19 TRAVERSE 29 148 XX1 30MM INNER
WIDTH DISC 28H ALLOY W/CHARCOAL DECAL
1
Rear wheel rim S193700010 27.5” Rim
RIM MY19 ROVAL TRAVERSE 27.5 RIM-670, 30MM WIDTH 28H W/
CHARCOAL DECAL
1
Tubeless valve stem ( in
small parts box)
S225500008 Tubeless conversion kit
WHL SUB, ROVAL TUBELESS VALVE STEM - 40MM, MTB &
ROAD (1 PCS.)
1
Icr port S216500007 Cable routing port CBG MY22 LEVO ICR PORT KIT 2
Speed sensor kit S196800019 Speed sensor ELE MY20 MTB SL SYSTEM, SPEEDSENSOR KIT 1
Speed sensor grommet S216800021 Rubber grommet ELE TURBO MTB SPEED SENSOR GROMMET 1
Cable binder S166800007 Cable binder
ELE MY16 LEVO CABLE BINDER, MATERIAL: CB6-185, ABS+FIBER
(PA66+G30%), 3X PER FSR (2 AT FRONT, 1 AT REAR)
2
Motor S226800001 Motor,m20 ELE MOTOR, SL SYSTEM, M20 1
Mud flap kit
S214200057
Mud flap SUB MY22 LEVO SL CARBON MUD FLAP KIT 1
Mud flap bolt M4 x 12 mm x 0,7 mm p, bolt SCR,CUST,M4X0.7 X 12,AL 2024-T6,BLK 2
Sram spider S215100003 Motor spider
SPR TURBO, SL SYSTEM, M20 MOTOR SPIDER, 104 BCD, 4-BOLT,
ALLOY, SRAM (00.6218.030.003)
1
Spider lock ring S225100001 Lock ring
SPR SUB, TURBO, SL SYSTEM, SL M20 MOTOR, SPIDER LOCK
RING
1
Chainring
S211400008
Sram 32t alloy ring 104 bcd ring
CHR SRAM CHAINRING EAGLE 32T 104BCD ALLOY EMTB W/
BOLTS (00.6218.040.000)
1
Chain ring bolts M8.5 X 5 mm x 1 mm p, bolt 4
Alloy crank arms - 165
mm
S211600036
Sram fc s699 mhl gen2 nrrw al 165 norng/
nospd
CRK TURBO, SL M20, MOUNTAIN, 165MM, L+R ARMS, ALLOY,
SRAM (11.6118.069.006)
1
Alloy crank arms - 170
mm
S211600037
Sram fc s699 mhl gen2 nrrw al 170 norng/
nospd
CRK TURBO, SL M20, MOUNTAIN, 170MM, L+R ARMS, ALLOY,
SRAM (11.6118.069.003)
1
Alloy crank arms - 175
mm
S211600038
Sram fc s699 mhl gen2 nrrw al 175 norng/
nospd
CRK TURBO, SL M20, MOUNTAIN, 175MM, L+R ARMS, ALLOY,
SRAM (11.6118.069.000)
1
Carbon crank arms -
165 mm
S211600039
Sram fc s996 mhl gen2 nrrw c 165 norng/
nospdr
CRK TURBO, SL M20, MOUNTAIN, 165MM, L+R ARMS, CARBON,
SRAM (11.6118.067.006)
1
Carbon crank arms -
170 mm
S211600040
Sram fc s996 mhl gen2 nrrw c 170 norng/
nospdr
CRK TURBO, SL M20, MOUNTAIN, 170MM, L+R ARMS, CARBON,
SRAM (11.6118.067.003)
1
Carbon crank arms -
175 mm
S211600041
Sram fc s996 mhl gen2 nrrw c 175 norng/
nospdr
CRK TURBO, SL M20, MOUNTAIN, 175MM, L+R ARMS, CARBON,
SRAM (11.6118.067.000)
1
Shock link kit - carbon
S214300007
SHL MY22 LEVO SL CARBON, SHOCK LINK 1
Shock link Carbon shock link LINK,MTB,PA TRAIL FSR G1,29F/27.5R,ALY 1
Link bearing 12 mm id x 21 mm od x 5 mm w, ball bearing BRG,BALL,12MM ID X 21MM OD X 5MM W,DBL SLD 6
Shock extension kit -
Carbon
S216300005
SHK EXT MY22 LEVO SL CARBON, CARBON EXTENSION 1
Shock extension Carbon EXTN,MTB,PA TRAIL FSR G1,29F/27.5R,CRBN 1
Shock extension kit
- Alloy
S216300004
Shk ext my22 Levo SL Carbon, Alloy extension 1
Shock extension Alloy EXTN,MTB,PA TRAIL FSR G1,AL 1
