50
A
B
1 2
6.5.6. FRONT WHEEL
1. Use a 6 mm hex key to loosen the pinch bolt (B), then install the front wheel into the fork dropouts. Insert front
wheel between the dropouts making sure the brake disc is between the brake caliper pads. Slide the thru-axle (A)
through the drive side dropout and hub.
Place the bicycle on the floor and compress the fork a couple of times to ensure that the lower leg has settled into
its low-friction point.
2. Use a torque wrench and a 6 mm hex bit to torque the thru-axle (clockwise) to the manufacturer’s torque
specification. Use a torque wrench and a 6 mm hex bit to torque the pinch bolt on the drive side dropout to
manufacturer’s torque specification.
