95
17.4.8.141BSensor head cable (GI-D7/GI-N8) Long cable
A junction box and interconnecting cable are
added for cables 30m(15m) or longer.
GI-D7:
30,35,40,50m
GI-N8:
15,20,25,30m
①
Sensor side cable (2m)
②
Long cable( 2x2m)
③
Control side cable (2m)
The figure is a constitution example of
WIB-N3 socket-type (GI-D7).
Fig. 17-15 Long cabel (GI-D7/GI-N8)
1
2
3
