11.4.9. Reading the measured pressure value and action status
Command
Parameter
Response
Explanation of function
‘RP’
－
‘ X.XXE-XX ’
Reads measured pressure data
‘PR’
－
‘ON’ or ‘OF’
Reads EXT-PROTECT status
‘RS’
‘ XXXXXXX ’
Reads action status
Send back `0.00E-XX ` for a ,` RP' command in filament OFF.
The `PR' command send back in an input state of EXT-PROTECT of IO.
ON： There is INPUT, OFF: There is not INPUT.
‘RS’command respose details:
X1 + X2 + X3 + ... + X7 and data of seven items (X:0/1) is one set, and it is replied.
The details of data are as follows.
Items
0
１
X1
Fil 2/1
（
Setting condition
）
Fil2
Fil1
X2
Fil ON/OFF
OFF
ON
X3
Em Valid
NG
OK
X4
DeGas ON/OFF
OFF
ON
X5
PROTECT
(Pressure protection
）
OFF
ON
X6
SetPoint2 ON/OFF
OFF
ON
X7
SetPoint1 ON/OFF
OFF
ON
11.5. Cautions in Operation
(1) Operation from the front panel is not accepted after the remote status is set up by
RS-232C communication.
(2) Operation from an external input is not accepted after the remote status is set up
by RS-232C communication.
However, EXT-PROTECT is active.
(3) If the filament is ON (including degassing ON) when the remote status is set up
by RS-232C communication, the action will be turned OFF.
(4) If the filament is ON (including degassing ON) when the remote status is reset
from the remote status to the local status through RS-232C communication, control
returns to the local status after turning OFF the action.
(5) If the RS-232C remote status is set up from the host computer and the power to
the host computer is turned OFF before it is reset to the local status, the vacuum
gauge side holds the remote status. To reset it, enter a local command from the
host computer again or turn OFF the power to the vacuum gauge.
