Ulvac GI-M2 - Standard Accessories; Options

7
Power
requirements
ＡＣ１００±１０Ｖ ５０／６０Ｈｚ
Power
consumption
60VA 120VA 65VA
Fuse
BS.SEMKO EWM 3.15A (Fuji Terminal Industry) (2 pc)
Outside
dimensions
240W × 380D × 99H (mm)
Weight
5.6
ｋｇ
5.7
ｋｇ
5.8kg
※1） Pressure display can set that mantissa part 2 digits, exponent part 2 digits digital display
(□.□□ × 10□□).
※2） 10 µA and 1.0 mA are automatically changed over depending on pressure,
1.0 mA is available when the pressure measurement value is 0.79 × 10
-2
Pa or less
※3）
Emission current of 5.0 mA is available under a pressure of 6.6 × 10
-4
Pa or less.
※4） When use a tungsten filament, it is necessary to do pressure protection of a set point of
functioning in 9.9×10
-3
Pa
※5）
Available under a pressure of 1.3 × 10
-4
Pa or less.
2.2. Standard Accessories
External input/output connector
57-30500: DDK or equivalent
1 pc.
Power cable
125 V, 7 A, 3-pin cable, 3 m long
1 pc.
Quick manual
Ordinary paper
1pc
This gauge does not come with the RS-232C communication cable.
Use a commercially available RS-232C cable (cross type).
2.3. Options
Sensor head
Refer to P.86
～
for the each sensor head details.
Refer to P.86
～
for the demontions details.
Sensor head cable
Ref er to P.89
～
for the details.
Inspection record
Calibration certificate
Calibration certificate, JCSS Calibration certificate
