4.4.3.Connection of sensor head and sensor head cable (GI-D7/GI-N8)
Fig. 4-5 WIT connection
Electrode
name
Sensor
head name
（WIB）
Sensor
head name
（WIT）
Cable name
FIlament
F
(2x
２
places)
F(
２
places)
F
１、
F2
F1
、
F2 (One set with each 2)
WIT is only F1
Glit
G(
２
places)
G(
２
places)
G
One set with each 2
Collector
Non sign
P(2places)
C
Connect a Co-axial cable
Fig. 4-6 WIB(WIT) Connection
WIT
WIT socket type
WIB
（WIT）
WIB pin socket type
Collector
Display of electrode
name
Display of cable name
