Unify OpenStage 40 User Manual

122 Individual phone configuration
Adjusting audio settings
Optimize the audio settings on your OpenStage for your work environment and
according to your personal requirements.
Adjusting the receiving volume during a call
You are conducting a call.
+ or - Raise or lower the volume. Keep pressing the key until the desired volume is set.
i Save.
Adjusting the ring volume
+ or - Press one of the keys shown in idle mode Æ Page 25.
Confirm the option shown.
+ or - Raise or lower the volume. Keep pressing the key until the desired volume is set.
i Save.
Adjusting the ringer pitch
+ or - Press one of the keys shown in idle mode Æ Page 25.
Select and confirm the option shown.
+ or - To adjust the ringer pitch: Keep pressing the keys until the desired pitch is set.
i Save.
Adjusting the attention ring volume
If you are part of a team with trunk keys, other calls can be signaled acoustically
in the team during a call. You will hear the attention ring.
+ or - Press one of the keys shown in idle mode Æ Page 25.
Select and confirm the option shown.
+ or - Raise or lower the volume. Keep pressing the key until the desired volume is set.
i Save.
Ring volume
Ring tone
Attention Ring Vol.

Unify OpenStage 40 Specifications

General

Resolution	240 x 128 pixels
Full duplex	Yes
Camera included	No
Dimensions (WxDxH)	270 x 220 x 70 mm
Networking features	QoS
Supported network protocols	IEEE 802.1Q (VLAN), IEEE 802.1p
Dialer location	Base
Phonebook capacity	- entries
Volume control	Digital
Voice codecs	G.711, G.722
Display number of lines	6 lines
Display number of colors	Monochrome
Product color	Black, Silver
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	5 - 40 °C
Certification	CE, EMC EN55022 Cl. B, EN55024, EN61000-4-11, EN61000-3-2, EN60950-1, EMC (FCC) P.15 (CFR 47) Cl. B, UL60950-1/CSA 22.2 No950

Weight and Dimensions

Weight	1068 g
