Page #80 background imageLoading...
Page #80 background image
80 Privacy/security
Monitoring a room
You can use a phone to monitor a room. This function must be enabled on the
monitoring phone.
When you call this phone, you can immediately hear what is happening in that
room.
Activating the telephone to be monitored
N Open the Program/Service menu Æ Page 31.
Select and confirm the option shown.
You can either leave the telephone in speakerphone mode or lift the handset and
leave it directed towards the noise source.
Deactivating the telephone to be monitored
N Press the illuminated key. The LED goes out.
or
\ Replace the handset.
Monitoring the room
j Enter the internal station number of the phone located in the room that you wish
to monitor.
Trace call – identifying anonymous callers
(not for U.S.)
You can identify malicious external callers. You can record the caller's phone
number during a call or for up to 30 seconds after a call. You should not hang up
in the process.
N Open the Program/Service menu Æ Page 31.
Select and confirm the option shown.
Room monitor
Trace call
If the trace is successful, the transmitted data is stored by your network
operator. Consult your administrator.
