20 Getting to know the OpenStage
Keys
Function keys
Audio keys
Key Function when key is pressed
s End (disconnect) call Æ Page 38.
, Saved number redial (last number dialed) Æ Page 37.
r Button for call forwarding (with red key LED)
1
Æ Page 40.
1 If the key LED on your phone is flashing, your station has been set up as a forwarding destination.
O
Open mailbox (with red key LED) Æ Page 29.
N
Open Service Menu (with red LED key) Æ Page 31.
Key Function when key is pressed
o Activate/deactivate the headset Æ Page 46
p Activate/deactivate microphone (also for speakerphone mode) Æ Page 38
-
Set volume lower and contrast brighter Æ Page 120.
n Turn speaker on/off (with red key LED) Æ Page 35.
+
Set volume louder and contrast darker Æ Page 120.

Table of Contents

Other manuals for Unify OpenStage 40

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Unify OpenStage 40 and is the answer not in the manual?

Unify OpenStage 40 Specifications

General IconGeneral
Resolution240 x 128 pixels
Full duplexYes
Camera includedNo
Dimensions (WxDxH)270 x 220 x 70 mm
Networking featuresQoS
Supported network protocolsIEEE 802.1Q (VLAN), IEEE 802.1p
Dialer locationBase
Phonebook capacity- entries
Volume controlDigital
Voice codecsG.711, G.722
Display number of lines6 lines
Display number of colorsMonochrome
Product colorBlack, Silver
Storage temperature (T-T)-40 - 70 °C
Operating temperature (T-T)5 - 40 °C
CertificationCE, EMC EN55022 Cl. B, EN55024, EN61000-4-11, EN61000-3-2, EN60950-1, EMC (FCC) P.15 (CFR 47) Cl. B, UL60950-1/CSA 22.2 No950
Weight and Dimensions IconWeight and Dimensions
Weight1068 g
