Getting to know the OpenStage 19
BLF
The BLF is a key module attached to the side of the phone that provides 90 illuminated,
programmable keys.
Like keys on the phone, these keys can be programmed and used according to your needs
Æ Page 22.
You can only attach 1 BLF to your OpenStage 40/40 G.
Key labeling
Your BLF is delivered with label strips. Write functions or names in the white fields on the relevant
label strips.
Alternatively, you can use the Key Labeling Tool to conveniently create new label strips. You can
find this including instructions at
http://wiki.unify.com/wiki/Key_Labelling_Tool
Lay the labeled strips on the relevant key fields and place the transparent cover over them (rough
side up).
Your OpenStage 40/40 G can be configured as an attendant console in conjunction with an
BLF
(consult your administrator).

Unify OpenStage 40 Specifications

General

Resolution	240 x 128 pixels
Full duplex	Yes
Camera included	No
Dimensions (WxDxH)	270 x 220 x 70 mm
Networking features	QoS
Supported network protocols	IEEE 802.1Q (VLAN), IEEE 802.1p
Dialer location	Base
Phonebook capacity	- entries
Volume control	Digital
Voice codecs	G.711, G.722
Display number of lines	6 lines
Display number of colors	Monochrome
Product color	Black, Silver
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	5 - 40 °C
Certification	CE, EMC EN55022 Cl. B, EN55024, EN61000-4-11, EN61000-3-2, EN60950-1, EMC (FCC) P.15 (CFR 47) Cl. B, UL60950-1/CSA 22.2 No950

Weight and Dimensions

Weight	1068 g
