Unify OpenStage 40 User Manual

130 Web interface
User Pages
The web interface homepage opens once you have entered and confirmed the phone's IP
address.
1. Click a menu heading to display the individual menu entries. Click the menu heading again to
close the menu.
2. Click a menu entry to open the corresponding form.
3. Make the desired changes.
4. Click the corresponding button to save or discard your changes.
Button functions
•„Login": Log in to the phone after you have entered the user password
•„Submit": Apply changes
•„Reset": Reset original values
•„Refresh":Update the values.
•„Logout": Log out from the phone
User menu
You can also configure the following settings via the user menu on the phone.
User Pages
User login
Authentication
– Old password
– User password
V
Æ Page 81
– Confirm password
Ringer
– Ringer mode (
V
Æ Page 121)
– HiPath
– Local ringer
– Local ringers
V
Æ Page 123
–Name
– Internal
– Ringer file
– Pattern melody
– Pattern sequence
– External
– Ring tone
– Pattern melody
– Pattern sequence
– Attention
– Ringer file
– Pattern melody
– Pattern sequence

Unify OpenStage 40 Specifications

General

Resolution	240 x 128 pixels
Full duplex	Yes
Camera included	No
Dimensions (WxDxH)	270 x 220 x 70 mm
Networking features	QoS
Supported network protocols	IEEE 802.1Q (VLAN), IEEE 802.1p
Dialer location	Base
Phonebook capacity	- entries
Volume control	Digital
Voice codecs	G.711, G.722
Display number of lines	6 lines
Display number of colors	Monochrome
Product color	Black, Silver
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	5 - 40 °C
Certification	CE, EMC EN55022 Cl. B, EN55024, EN61000-4-11, EN61000-3-2, EN60950-1, EMC (FCC) P.15 (CFR 47) Cl. B, UL60950-1/CSA 22.2 No950

Weight and Dimensions

Weight	1068 g
