Unify OpenStage 40 User Manual

Enhanced phone functions 47
Using the speakerphone
A colleague addresses you directly over the speaker with a speaker call. You
hear a tone before the announcement. The other party’s name or station number
appears on the screen.
You can conduct the call with the handset or in speakerphone mode.
^ Lift the handset and answer the call.
or
Press the "OK" key to confirm your selection and answer the call.
or
p Press the key and answer.
Enabling and disabling handsfree answerback
c Open the idle menu Æ Page 26.
Select and confirm the option shown.
or
Select and confirm the option shown.
Mute off
If handsfree answerback is enabled (see below), you do not need to
switch on the microphone - you can answer directly. You can answer
immediately in speakerphone mode.
If handsfree answerback is disabled (default setting), follow the procedure
described above. Placing a speaker call to a colleague
Æ Page 56.
HF answerback on
HF answerback off

Unify OpenStage 40 Specifications

General

Resolution	240 x 128 pixels
Full duplex	Yes
Camera included	No
Dimensions (WxDxH)	270 x 220 x 70 mm
Networking features	QoS
Supported network protocols	IEEE 802.1Q (VLAN), IEEE 802.1p
Dialer location	Base
Phonebook capacity	- entries
Volume control	Digital
Voice codecs	G.711, G.722
Display number of lines	6 lines
Display number of colors	Monochrome
Product color	Black, Silver
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	5 - 40 °C
Certification	CE, EMC EN55022 Cl. B, EN55024, EN61000-4-11, EN61000-3-2, EN60950-1, EMC (FCC) P.15 (CFR 47) Cl. B, UL60950-1/CSA 22.2 No950

Weight and Dimensions

Weight	1068 g
