Unify OpenStage 40 User Manual

34 Basic functions
Accepting a call via the loudspeaker (speakerphone
mode)
Notes on using speakerphone mode
• Tell the other party that you are using speakerphone mode.
• The speakerphone works best at a low receiving volume.
• The ideal distance between the user and the telephone in speakerphone mode
is about 50 cm (approx. 20 inches).
The phone rings. The caller appears on the screen.
Pay attention to the notes on voice encryption Æ Page 77.
n Press the key shown. The LED lights up.
or
Confirm the option shown.
The speakerphone function is activated.
if nec. + or - Adjust the call volume. Keep pressing the key until the desired volume is set.
Ending the call
n Press the key shown. The LED goes out.
or
s Press the key shown.
Accepting a call via the headset
Prerequisite: A headset is connected.
The phone rings. The o key flashes.
o Press the key shown.
if nec. + or - Adjust the call volume.
Answer
Make sure your headset port is set up properly Æ Page 124.

Unify OpenStage 40 Specifications

General

Resolution	240 x 128 pixels
Full duplex	Yes
Camera included	No
Dimensions (WxDxH)	270 x 220 x 70 mm
Networking features	QoS
Supported network protocols	IEEE 802.1Q (VLAN), IEEE 802.1p
Dialer location	Base
Phonebook capacity	- entries
Volume control	Digital
Voice codecs	G.711, G.722
Display number of lines	6 lines
Display number of colors	Monochrome
Product color	Black, Silver
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	5 - 40 °C
Certification	CE, EMC EN55022 Cl. B, EN55024, EN61000-4-11, EN61000-3-2, EN60950-1, EMC (FCC) P.15 (CFR 47) Cl. B, UL60950-1/CSA 22.2 No950

Weight and Dimensions

Weight	1068 g
