Unify OpenStage 40 User Manual

Programming sensor keys 73
Configuring repdial keys
You can also program internal and external station numbers at the second level.
The LED function is not available for internal station numbers at the second
level. A "Shift" key
Æ Page 69 has to be configured in order to program the
second level.
See also Æ Page 22.
S Hold down the key shown.
Confirm the option shown.
or
N Open the Program/Service menu Æ Page 31.
Select and confirm the option shown.
S Press the key shown.
Confirm the option shown.
if nec.
Select and confirm the option shown.
Confirm the option shown.
Confirm the option shown.
j Enter the phone number.
If you make a mistake:
a Press this key. This deletes all entered digits.
Confirm the option shown.
or
Select and confirm the option shown.
or
Select and confirm to assign the label Æ Page 74.
Assign telephony function
Prog. feature key
Change key
+=Next level
Destinations g
Repdial key
Exit
Another key
Key label
You dial the saved number by pressing the key Æ Page 37.
You can also save a number during a call.

Unify OpenStage 40 Specifications

General

Resolution	240 x 128 pixels
Full duplex	Yes
Camera included	No
Dimensions (WxDxH)	270 x 220 x 70 mm
Networking features	QoS
Supported network protocols	IEEE 802.1Q (VLAN), IEEE 802.1p
Dialer location	Base
Phonebook capacity	- entries
Volume control	Digital
Voice codecs	G.711, G.722
Display number of lines	6 lines
Display number of colors	Monochrome
Product color	Black, Silver
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	5 - 40 °C
Certification	CE, EMC EN55022 Cl. B, EN55024, EN61000-4-11, EN61000-3-2, EN60950-1, EMC (FCC) P.15 (CFR 47) Cl. B, UL60950-1/CSA 22.2 No950

Weight and Dimensions

Weight	1068 g
