Unify OpenStage 40 User Manual

40 Basic functions
Forwarding calls
Using variable call forwarding
You can immediately forward internal or external calls to different internal or
external telephones (destinations). (External destinations require special
configuration in the system.)
r Press the key shown.
or
c Open the idle menu Æ Page 26.
Select and confirm the option shown.
Confirm the option shown.
or
Select and confirm the option shown.
or
Select and confirm the option shown.
j Enter the destination number.
Confirm the option shown.
The call forwarding symbol as well as the phone number and possibly also the
forwarding destination name are displayed.
Deactivating call forwarding
r Press the key shown.
or
c Open the idle menu Æ Page 26.
Select and confirm the option shown.
When call forwarding is active, a special dial tone sounds when you lift the
handset.
If DID DTMF is active (consult your administrator), you can also forward
calls to this destination. Destinations: Fax = 870, DID = 871, Fax-DID =
872.
If you are a call forwarding destination, the call forwarding key will flash
Æ Page 20.
Special features must be taken into consideration if your telephone
operates with system networking via LAN
Æ Page 116!
Forwarding on
1=all calls
2=external calls only
3=internal calls only
Save
K 100168
Forwarding off

Unify OpenStage 40 Specifications

General

Resolution	240 x 128 pixels
Full duplex	Yes
Camera included	No
Dimensions (WxDxH)	270 x 220 x 70 mm
Networking features	QoS
Supported network protocols	IEEE 802.1Q (VLAN), IEEE 802.1p
Dialer location	Base
Phonebook capacity	- entries
Volume control	Digital
Voice codecs	G.711, G.722
Display number of lines	6 lines
Display number of colors	Monochrome
Product color	Black, Silver
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	5 - 40 °C
Certification	CE, EMC EN55022 Cl. B, EN55024, EN61000-4-11, EN61000-3-2, EN60950-1, EMC (FCC) P.15 (CFR 47) Cl. B, UL60950-1/CSA 22.2 No950

Weight and Dimensions

Weight	1068 g
