14 Getting to know the OpenStage
Getting to know the OpenStage
The following sections describe the most frequently used controls and displays.
The user interface of your OpenStage 40/40 G
1 You can make and receive calls as normal using the handset.
2The display permits intuitive operation of the phone
Æ Page 25.
3
You can customize your telephone by assigning phone numbers and functions to the
programmable sensor keys
Æ Page 22.
4
You can use function keys when conducting a call to access frequently used functions
(such as Disconnect/Release) or to open the Service Menu and mailbox
Æ Page 20.
5
Audio keys are also available, allowing you to optimally configure the audio features of your
telephone
Æ Page 20.
6The 5-way navigator is a convenient navigation tool
Æ Page 21.
7The dialpad can be used to enter phone numbers and write text
Æ Page 23.
8 Incoming calls are visually signaled via the call display.
5
7
1
6
4
8
2
3

Unify OpenStage 40 Specifications

General

Resolution	240 x 128 pixels
Full duplex	Yes
Camera included	No
Dimensions (WxDxH)	270 x 220 x 70 mm
Networking features	QoS
Supported network protocols	IEEE 802.1Q (VLAN), IEEE 802.1p
Dialer location	Base
Phonebook capacity	- entries
Volume control	Digital
Voice codecs	G.711, G.722
Display number of lines	6 lines
Display number of colors	Monochrome
Product color	Black, Silver
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	5 - 40 °C
Certification	CE, EMC EN55022 Cl. B, EN55024, EN61000-4-11, EN61000-3-2, EN60950-1, EMC (FCC) P.15 (CFR 47) Cl. B, UL60950-1/CSA 22.2 No950

Weight and Dimensions

Weight	1068 g
