Getting to know the OpenStage 21
5-way navigator
This control allows you to manage most of your phone's functions as well as its displays.
Remove the protective film from the ring around the 5-way navigator before using the phone.
Operation Functions when key is pressed
Press the
c key.
In idle mode:
• Open the idle menu
Æ Page 26
In lists and menus:
• Go to next level
You can now access a context menu:
• Open the context menu
Press the
a key.
In lists and menus:
• Go back one level or go back to the telephony
interface by pressing several times
During en-bloc dialing:
• Delete character to the left of the cursor
Press the
d key.
In lists and menus:
• Scroll down
• Long press (key held down): Jump to the end of
the list/menu
Press the
b key.
In lists and menus:
• Scroll up
• Long press (key held down): Jump to the start of
the list/menu
Press the
i key.
In idle mode:
• Open the idle menu
Æ Page 26
Entry selected:
• Perform action

Unify OpenStage 40 Specifications

General

Resolution	240 x 128 pixels
Full duplex	Yes
Camera included	No
Dimensions (WxDxH)	270 x 220 x 70 mm
Networking features	QoS
Supported network protocols	IEEE 802.1Q (VLAN), IEEE 802.1p
Dialer location	Base
Phonebook capacity	- entries
Volume control	Digital
Voice codecs	G.711, G.722
Display number of lines	6 lines
Display number of colors	Monochrome
Product color	Black, Silver
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	5 - 40 °C
Certification	CE, EMC EN55022 Cl. B, EN55024, EN61000-4-11, EN61000-3-2, EN60950-1, EMC (FCC) P.15 (CFR 47) Cl. B, UL60950-1/CSA 22.2 No950

Weight and Dimensions

Weight	1068 g
