Unify OpenStage 40 User Manual

Local user menu 136
Configuration (not supported by HiPath 3000)
– Outgoing calls
Æ Page 125
– Block dialling
– Activated
– Deactivated
Phone
– Display Æ Page 120
– Helligkeit:
Change user password?
– Current password: Æ Page 81
– New user password:
– Confirm password:
– Options: Save & exit
Network information?
– Options: Exit
– Phone address:
Æ Page 126
– Web address:
– IP address:
– LAN RX:
– LAN TX:
– PC RX:
– PC TX:
– LAN autonegotiated:Yes
– LAN information: 10 Mbps full duplex
– PC autonegotiated : Yes
– PC information:Link down
– Back?

Unify OpenStage 40 Specifications

General

Resolution	240 x 128 pixels
Full duplex	Yes
Camera included	No
Dimensions (WxDxH)	270 x 220 x 70 mm
Networking features	QoS
Supported network protocols	IEEE 802.1Q (VLAN), IEEE 802.1p
Dialer location	Base
Phonebook capacity	- entries
Volume control	Digital
Voice codecs	G.711, G.722
Display number of lines	6 lines
Display number of colors	Monochrome
Product color	Black, Silver
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	5 - 40 °C
Certification	CE, EMC EN55022 Cl. B, EN55024, EN61000-4-11, EN61000-3-2, EN60950-1, EMC (FCC) P.15 (CFR 47) Cl. B, UL60950-1/CSA 22.2 No950

Weight and Dimensions

Weight	1068 g
