28 Getting to know the OpenStage
Appearance during an ongoing call
Example: You are connected to a caller.
Icons for frequent call states
Icon Meaning
The call is active.
The call has been disconnected.
You have placed the call on hold (e.g. consultation hold).
Your call partner has placed the call on hold.
You are conducting a call over a secure connection.
You are conducting a call over a non-secure connection.
Detailed descriptions of the various functions can be found in the sections "Basic functions"
Æ Page 33 and "Enhanced phone functions" Æ Page 46.
Start conference
Smith Michael 3:16
100168
Consultation
Start transfer
Directory
Icons indicating call status
Call duration
Current connection
Options relevant to situation; scroll bar shows that more
options are available.

Unify OpenStage 40 Specifications

General

Resolution	240 x 128 pixels
Full duplex	Yes
Camera included	No
Dimensions (WxDxH)	270 x 220 x 70 mm
Networking features	QoS
Supported network protocols	IEEE 802.1Q (VLAN), IEEE 802.1p
Dialer location	Base
Phonebook capacity	- entries
Volume control	Digital
Voice codecs	G.711, G.722
Display number of lines	6 lines
Display number of colors	Monochrome
Product color	Black, Silver
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	5 - 40 °C
Certification	CE, EMC EN55022 Cl. B, EN55024, EN61000-4-11, EN61000-3-2, EN60950-1, EMC (FCC) P.15 (CFR 47) Cl. B, UL60950-1/CSA 22.2 No950

Weight and Dimensions

Weight	1068 g
