16.SPECIFICATIONS
112
Input signal: BCD data hold, logic switching
Input type: Dead-front contact input
(self-contained power supply)
Relay, switch, and transistor, etc.
can be connected.
The signal is inputed by short-circuited
and opening the input terminal
of the terminal COM.
When the transistor is connected,
NPN output type (sink type) is connected.
Current when short-circuited About 6mA
Insulation method: Photo coupler insulation
BCD parallel data output interface
(source type) [BSC]
Output signal: Indicated value data (5-digit), near zero,
minus, over, stable, strobe
Output logic: Switching between positive logic and
negative logic
Output type: Source type
When signal ON, output transistor ON.
When the input unit such as PLC is
connected, minus common is connected.
Rated voltage: 30V
Rated current: 20mA
Insulation method: Photo coupler insulation
Input signal: BCD data hold, logic switching
Input type: Minus common
Relay, switch, and transistor, etc.
can be connected.
The signal is inputed by short-circuited
and opening the input terminal
of the terminal COM.
When the transistor is connected, PNP
output type (source type) is connected.
ON voltage: 9V or more
OFF voltage: 3V or less
At 24V load: About 5mA
Insulation method: Photo coupler insulation
