16.SPECIFICATIONS
113
D/A converter (voltage output) [DAV]
Voltage output -10 to +10V
(load resistance; 2kΩ or more)
D/A conversion speed 2000 times/sec.
Resolution 1/10000
Over range -11.0 to +11.0V
Zero adjustment range Approx. -1.0 to +1.0V
(at the time of zero output)
Gain adjustment range Approx. 9.5 to 10.5V
(at the time of full scale output)
Zero drift Within 0.6mV/ ℃
Gain drift Within 50ppm/ ℃
Non-linearity Within 0.05%FS
* Not including the drift of the
analog input section
Output connector Screw type terminal block
(two-pole)
D/A converter (current output) [DAI]
Current output 4 to 20mA
(load resistance; 350Ω or less)
D/A conversion speed 2000 times/sec.
Resolution 1/10000
Over range 3.2 to 20.8mA
Zero adjustment range Approx. 3.6 to 4.4mA
(at the time of zero output)
Gain adjustment range Approx. 19.6 to 20.4mA
(at the time of full scale output)
Zero drift Within 0.5µA/ ℃
Gain drift Within 50ppm/ ℃
Non-linearity Within 0.05%FS
* Not including the drift of the
analog input section
Output connector Screw type terminal block
(two-pole)
To Next Page
