4.SETTING MODE CONFIGURATION
27
Setting Mode4
*Decimal point position synchronizes with the setting of decimal place of setting mode 3.
Item Default Setting range Set Value
LOCK
Calibration
LOCK
Reference
page
1
RS-485
Commu-
nication
Method
Baud rate 4
5 : 38400bps
4 : 19200bps
3 : 9600bps
2 : 4800bps
1 : 2400bps
0 : 1200bps
○
P.74
Character length 1 Fixed at 8 bits
Parity bit 2
2 : Even
1 : Odd
0 : None
Stop bit 0 Fixed at 1 bit
2
RS-485 ID
01 01 to 32
○
P.75
3
RS-485 Transmission
DeLay Time
00 00 to 99
○
P.76
4
BCD Data Update Rate
4
4 : 2000 times
3 : 1000 times
2 : 100 times
1 : 10 times
0 : 1 times
○
P.78
5
D/A Zero Setting
000.00
-19999 to 19999 *
○
P.97
6
D/A Full Scale Setting
100.00
-19999 to 19999 *
○
P.97
7
D/A Output Mode
0
3 : 20mA (10V) fixed output
2 : 4mA (0V) fixed output
1 : Linked with indicated
value
0 : Not linked with indicated
value
○
P.98
8
Password
0000 1239 : Initialization
P.99
Set values can be rewritten to factory-set values（default）.
For simple initialization, see “Password” on page 99 , and for
simultaneous self-check and initialization, see “Initialization” on page 103 .
To Next Page
