Vacon NX series Applications Manual

Table 45: Monitoring values, NXP drives
Index Monitoring value Unit ID Description
V1.21.7 Shaft Angle Deg 1169 See ID1090
V1.21.8 Sensor 1 Temp ºC 50 Sensor 1 temperature
V1.21.9 Sensor 2 Temp ºC 51 Sensor 2 temperature
V1.21.10 Sensor 3 Temp ºC 52 Sensor 3 temperature
V1.21.11
Encoder 2 Fre-
quency
Hz 53
From OPTA7 board (input C.3)
V1.21.12
Absolute encoder
position
54
From OPTBB board
V1.21.13
Absolute encod.
rotations
55
From OPTBB board
V1.21.14 ID Run Status 49
V1.21.15 PolePairNumber 58 Used PPN from motor nom. values
V1.21.16 Analogue input 1 % 59 AI1
V1.21.17 Analogue input 2 % 60 AI2
V1.21.18 * Analogue input 3 % 61 AI3
V1.21.19 * Analogue input 4 % 62 AI4
V1.21.20 Analogue output 2 % 31 AO2
V1.21.21 Analogue output 3 % 32 AO3
V1.21.22
Final Frequency Ref-
erence Closed Loop
Hz 1131
Used for Closed Loop speed tuning
V1.21.23 Step Response Hz 1132 Used for Closed Loop speed tuning
V1.21.24 Output power kW 1508 Drive output power in kW
V1.21.25 Sensor 4 Temp ºC 69 Sensor 4 temperature
V1.21.26 Sensor 5 Temp ºC 70 Sensor 5 temperature
V1.21.27 Sensor 6 Temp ºC 71 Sensor 6 temperature
V1.22.1 * FB torque reference % 1140 Default control of FB PD In 1
V1.22.2 * FB limit scaling % 46 Default control of FB PD In 2
V1.22.3 * FB adjust reference % 47 Default control of FB PD In 3
V1.22.4 * FB analogue output % 48 Default control of FB PD In 4
V1.22.5 Last Active Fault 37
VACON · 134 MULTI-PURPOSE CONTROL APPLICATION
6
TEL. +358 (0)201 2121 · FAX +358 (0)201 212 205

Vacon NX series Specifications

General

Product type	AC Drive
Output voltage range	0-Uin
Frequency range	0-500 Hz
Enclosure classes	IP00, IP21
Mounting types	Wall
Braking chopper	Integrated or external
EMC filter	Built-in or external
Control modes	Scalar, Vector
Protection features	Overcurrent, overvoltage, undervoltage, overtemperature, short circuit
Communication options	Modbus, Profibus, CANopen, Ethernet
Ambient temperature range	-10°C to +50°C
Cooling method	Air-cooled
