Table 65: Limit settings (Control keypad: Menu M2 -> G2.3.4)
Index Parameter Min Max Unit Default Cust ID Description
P2.3.4.1
Output frequency
limit 1 supervision
0 3 0 315
0 = No supervision
1 = Low limit
supervision
2 = High limit
supervision
3 = Brake-on con-
trol
P2.3.4.2
Output frequency
limit 1; Supervised
value
0.00 320.00 Hz 0.00 316
P2.3.4.3
Output frequency
limit 2 supervision
0 4 0 346
0 = No supervision
1 = Low limit
supervision
2 = High limit
supervision
3 = Brake-off con-
trol
4 = Brake on/off
control
P2.3.4.4
Output frequency
limit 2; Supervised
value
0.00 320.00 Hz 0.00 347
P2.3.4.5
Torque limit
supervision
0 3 0 348
0 = No supervision
1 = Low limit
supervision
2 = High limit
supervision
3 = Brake-off con-
trol
P2.3.4.6
Torque limit
supervision value
-300.0 300.0 % 100.0 349
For brake control
absolute values
are used.
P2.3.4.7
Reference limit
supervision
0 2 0 350
0 = No supervision
1 = Low limit
2 = High limit
P2.3.4.8
Reference limit
supervision value
0.0 100.0 % 0.0 351
0.0 = Min fre-
quency
100.0 = Max fre-
quency
