Vacon NX series Applications Manual

Table 72: NXS drives: Closed Loop parameters (Control keypad: Menu M2 ->G2.6.23)
Index Parameter Min Max Unit Default Cust ID Description
P2.6.17.1
Magnetizing cur-
rent
0.00 2 x I
H
A 0.00 612
If zero internally
calculated.
P2.6.17.2 Speed control P 1 1000 30 613
P2.6.17.3
Speed control I
time
-3200.0 3200.0 ms 100.0 614
Negative value
uses 1 ms accu-
racy instead of 0.1
ms.
P2.6.17.5
Acceleration
compensation
0.00 300.00 s 0.00 626
P2.6.17.6 Slip adjust 0 500 % 75 619
P2.6.17.7
Magnetizing cur-
rent at start
0.00 I
L
A 0.00 627
P2.6.17.8
Magnetizing time
at start
0 32000 ms 0 628
P2.6.17.9
0-speed time at
start
0 32000 ms 100 615
P2.6.17.10
0-speed time at
stop
0 32000 ms 100 616
P2.6.17.11 Start-up torque 0 3 0 621
0 = Not used
1 = Torque mem-
ory
2 = Torque refer-
ence
3 = Start-up torque
fwd/rev
P2.6.17.12
Start-up torque
FWD
-300.0 300.0 s 0.0 633
P2.6.17.13
Start-up torque
REV
-300.0 300.0 s 0.0 634
P2.6.17.15
Encoder filter
time
0.0 100.0 ms 0.0 618
MULTI-PURPOSE CONTROL APPLICATION VACON · 171
24-HOUR SUPPORT +358 (0)201 212 575 · EMAIL: VACON@VACON.COM
6

Vacon NX series Specifications

General

Product type	AC Drive
Output voltage range	0-Uin
Frequency range	0-500 Hz
Enclosure classes	IP00, IP21
Mounting types	Wall
Braking chopper	Integrated or external
EMC filter	Built-in or external
Control modes	Scalar, Vector
Protection features	Overcurrent, overvoltage, undervoltage, overtemperature, short circuit
Communication options	Modbus, Profibus, CANopen, Ethernet
Ambient temperature range	-10°C to +50°C
Cooling method	Air-cooled
