454 MOTOR REGULATOR ACTIVATION * 67 (2.3.3.23, 2.3.1.23)
One of the limit regulators (current limit, torque limit) has been activated.
455 FIELDBUS DIGITAL INPUT 1 * 67 (2.3.3.24, 2.3.1.24)
456 FIELDBUS DIGITAL INPUT 2 * 67 (2.3.3.25, 2.3.1.25)
457 FIELDBUS DIGITAL INPUT 3 * 67 (2.3.3.26, 2.3.1.26)
The data from the fieldbus (Fieldbus Control Word) can be led to AC drive digital outputs. See
the fieldbus manual for details. See also ID169 and ID170.
458 AUTOCHANGE 1/AUXILIARY DRIVE 1 CONTROL 7 (2.3.1.27)
Control signal for autochange/auxiliary drive 1.
Default programming: B.1
459 AUTOCHANGE 2/AUXILIARY DRIVE 2 CONTROL * 7 (2.3.1.28)
Control signal for autochange/auxiliary drive 2.
Default programming: B.2
460 AUTOCHANGE 3/AUXILIARY DRIVE 3 CONTROL * 7 (2.3.1.29)
Control signal for autochange/auxiliary drive 3. If three (or more) auxiliary drives are used,
we recommend to connect nr 3, too, to a relay output. Since the OPTA2 board only has two
relay outputs it is advisable to purchase an I/O expander board with extra relay outputs (e.g.
Vacon OPTB5).
461 AUTOCHANGE 4/AUXILIARY DRIVE 4 CONTROL * 7 (2.3.1.30)
Control signal for autochange/auxiliary drive 4. If three (or more) auxiliary drives are used,
we recommend to connect nr 3 and 4, too, to a relay output. Since the OPTA2 board only has
two relay outputs it is advisable to purchase an I/O expander board with extra relay outputs
(e.g. Vacon OPTB5).
462 AUTOCHANGE 5 CONTROL * 7 (2.3.1.31)
Control signal for autochange drive 5.
463 ANALOGUE INPUT SUPERVISION LIMIT * 67 (2.3.3.22, 2.3.1.22)
The selected analogue input signal goes beyond the set supervision limits (see parameters
ID372, ID373 and ID374).
464 ANALOGUE OUTPUT 1 SIGNAL SELECTION * 234567 (2.3.1, 2.3.5.1, 2.3.3.1)
Connect the AO1 signal to the analogue output of your choice with this parameter. For more
information about the TTF programming method, see Chapter 8.9 "Terminal to function" (TTF)
programming principle.
VACON · 296 PARAMETER DESCRIPTIONS
8
TEL. +358 (0)201 2121 · FAX +358 (0)201 212 205
