Table 27: Output signals, G2.3
Index Parameter Min Max Unit Default Cust ID Description
P2.3.24 *
Analogue output 2
filter time
0.00 10.00 s 1.00 473
0 = No filtering
P2.3.25 *
Analogue output 2
inversion
0 1 0 474
0 = Not inverted
1 = Inverted
P2.3.26 *
Analogue output 2
minimum
0 1 0 475
0 = 0 mA (0 V)
1 = 4 mA (2 V)
P.2.3.27 *
Analogue output 2
scaling
10 1000 % 1.00 476
* = Use TTF method to program these parameters
