Table 34: Monitoring values
Index Monitoring value Unit ID Description
V1.1 Output frequency Hz 1 The output frequency to motor
V1.2 Frequency reference Hz 25 The frequency reference to motor control
V1.3 Motor speed rpm 2 The actual speed of the motor in rpm
V1.4 Motor current A 3
V1.5 Motor torque % 4 The calculated shaft torque
V1.6 Motor power % 5 The calculated motor shaft power in percentage
V1.7 Motor voltage V 6 The output voltage to motor
V1.8 DC link voltage V 7 The measured voltage in the DC-link of the drive
1.9 Unit temperature °C 8 The heatsink temperature in Celsius or Fahrenheit
1.10 Motor temperature % 9
The calculated motor temperature in percentage
of the nominal working temperature
V1.11 Analogue input 1 V/mA 13 AI1
V1.12 Analogue input 2 V/mA 14 AI2
V1.13 Analogue input 3 27 AI3
V1.14 Analogue input 4 28 AI4
V1.15 DIN 1, 2, 3 15 Shows the status of the digital inputs 1-3
V1.16 DIN 4, 5, 6 16 Shows the status of the digital inputs 4-6
V1.17 DO1, RO1, RO2 17
Shows the status of the digital and relay outputs
1-3
V1.18 Analogue I
out
mA 26 AO1
V1.19 PID Reference % 20 In % of the max. frequency
V1.20 PID Actual value % 21 In % of the max. actual value
V1.21 PID Error value % 22
The error value of the PID controller. It is the devi-
ation of feedback from the setpoint in process
units. You can use a parameter to make the selec-
tion of the process unit.
V1.22 PID Output % 23
The PID output as a percentage (0-100%). It is pos-
sible to give this value to the motor control (fre-
quency reference) or to an analogue output.
V1.23
Special display for
actual value
29
See parameters 2.2.46 to 2.2.49
