Vaisala Indigo500 Series - Figure 3 Indigo520 Cable Gland and Conduit Options, Example

3
2
2 1
4
2
2 1
1
2
2 1
3
2
2 1
5
Figure 3 Indigo520 cable gland and conduit
options, example configurations
1 Cable gland, M20×1.5
2 Cable gland, M16×1.5
3 Cable gland with split bushing,
M20×1.5
4 Conduit fitting, M20×1.5 for NPT1/2"
conduit
5 Pressure port, barometer module
Indigo510, Indigo520 User Guide M212287EN-N
16
