Section 5 - Operation MC122 - MCP-4J Control Unit
72
Pattern Mode - Example - Continued
6. If the Delay Length is acceptable, press the Right Arrow Button to view the Pattern Length for pattern 3.
Press the OK Button to view the thumbwheel, and use the Plus/Minus Buttons to change. Press the OK
Button to enter the setting.
7. All three patterns are now set. To review them, use the Left Arrow Button.
8. Use the Left and Right Arrow Buttons to review all information as desired. All three patterns have been
set and the Pattern Glue Mode for Valve 1 is now ready.
