Ver-Mac 2016 V-Touch Controller User Manual, V3.0 6
3.1.1 What You See in the Home Screen
Operation buttons arranged vertically on the left of the window.
Title bar (including power supply, schedule and hardware changes
indicators) at the top.
Preview area with Current Message as displaying on the PCMS.
Power supply information.
Brightness indicating the photocell reading, and the current sign intensity.
QuickPick bank of graphic images that are often used.
Status information about the operating state of the PCMS. Additional
information can be located within the troubleshooting section.
Operation Buttons on Home Screen
Displays the Home Screen.
Access to Play message screen.
Stop the current message and blank the PCMS.
Access to Edit Message functions.
Toggles between Options and message buttons.
Log out from all Operations.
Access to Options menu for the Touchscreen Controller.
Access to Parameters menu for the Touchscreen Controller.
Table 1 - Operations buttons on Home screen
3.2 QuickPick Image Bank
This feature contains the graphic traffic indications that are used most often on all
signboards, no matter what their size.
To select and display the graphic image you need, tap the image once.
After a brief message, your selected image shows in Preview area of the Home
screen and displays on the PCMS.
The QuickPick image bank will replace the current message on your PCMS unit.
