Ver-Mac 2016 V-Touch Controller User Manual, V3.0 11

Icon

Function

Opens a blank New message.

Opens Select Message screen allowing you to locate a

previous message to edit from the Collection of changeable

messages.

Add New page to message.

Remove page from message.

Opens Page Time window.

Opens the Font selection and Character spacing window.

Opens Select a Special Tag window.

Opens Page Conditions window for Radar and IO triggered

messages.

Allows you to insert existing Graphics into a message.

Text alignment, left, center, right.

Line alignment, toward top, mid-page, bottom.

Opens line Flash Time window.

Opens Moving Text window.

Applies the autofont feature so text can resizes according to

content.

Opens display Colors window.

Table 4 - Edit Message Toolbar icons

Table of Contents6
Figures and Tables7
Introduction9
Using a Touchscreen9
Security and Login10
User Profiles10
Authentication Screen11
Community Names11
Figure 1 - Select Security Level Window11
Figure 2 - Community Names12
Home Screen13
Explore the Home Screen13
Figure 3 - Home Screen13
Quickpick Image Bank14
Table 1 - Operations Buttons on Home Screen14
Display a Message15
Explore the Select Message Screen15
Figure 4 - Select Message Screen15
Select and Display an Existing Message16
Remove a Message from the Collection of Changeable Messages16
Table 2 - Toolbar Icons- Select Message16
Blank the Signboard17
Create a Message18
Explore Edit Message Screen18
Figure 5 - Edit Message Screen18
Table 3 - Keys to Change Keyboard Layout18
Table 4 - Edit Message Toolbar Icons19
Special Tags22
Figure 6 - Select a Special Tag Screen22
Table 5 - Dynamic Data Types23
Page Conditions24
Figure 7 - Radar Trigger Page Conditions24
Figure 8 - Page Conditions - no Ios Active25
Table 6 - Message Pages Attached to IO Operative Status in Page Conditions Window26
Import a Graphic into a Message27
Figure 9 - Select Message Screen-Graphic Image Bank27
Moving Text28
Figure 10 - Moving Text Window28
Table 7 - Moving Text Settings28
Auto Font Feature29
Colors29
Figure 11 - Autofont Feature29
Figure 12 - Colors Settings29
Figure 13 - Color Picker Screen29
Figure 14 - Color Picker - Color Zone30
Schedules31
Figure 15 - Access to Schedule Functions (Admin User)31
Explore Schedule Editor32
Figure 16 - Schedule Editor - Month Screen32
Figure 17 - Schedule Editor - Day Screen33
Create a New Schedule of Messages34
Table 8 - Content Areas of Edit Schedule-Day Screen34
Figure 18 - Building a Day Plan35
Table 9 - Day Plan Icons and Buttons36
Figure 19 - Periodicity Window with Default Settings37
Table 10 - Periodicity - Repetition Options38
Edit an Existing Schedule39
Table 11 - Editing Options for Schedules39
Figure 20 - Reviewing a Schedule40
Options41
Explore the Options Screen41
Figure 21 - Options Screen41
Table 12 - Options42
Table 13 - Other Options42
Brightness43
Figure 22 - Testing for Brightness43
Pixel Test44
Figure 23 - Testing for Faulty Pixels44
Maintenance45
Figure 24 - Maintenance Tests45
Devices46
Edit Graphic46
Figure 25 - List of Active Devices46
Figure 26 - Edit Graphic Screen46
Table 14 - Edit Graphic Screen Toolbar Icons47
Schedules48
Figure 27 - Color Picker Window48
Default Messages49
Figure 28 - Default Messages Screen49
Display Detection50
Figure 29 - Display Detection Screen50
Countdown Timer51
Data Management51
Figure 30 - Countdown Window51
Figure 31 - USB Data Connector51
Figure 32 - Data Management - Import Screen52
Table 15 - Operations Available Within Data Management52
Current Max53
Figure 33 - Data Management - Export Screen53
Sign Type54
GPS Modem54
Figure 34 - GPS Modem Screen54
Sign Up/Down55
Radar Configuration55
Figure 35 - Truck Mounted Sign Position Window55
Gps56
Figure 36 - GPS Screen56
Power Saving Options57
Figure 37 - Default NTCIP Parameters57
Figure 38 - Power Saving Options57
Parameters58
Figure 39 - Parameters Screen58
Guest Management59
Figure 40 - Guest Management Screen59
Table 16 - Operations Buttons-Parameters Screen59
Change Admin Password/Guest Password60
Network Settings60
Figure 41 - Enter Old Password Window60
Figure 42 - Network Window60
Special Code61
System Clock61
Figure 43 - Clock Configuration - Manual61
Diagnostics62
Interface Language Selector62
Figure 44 - Clock Configuration - NTP Client62
Figure 45 - Language Selector Screen62
Hardware Changes63
Figure 46 - Hardware Change(S) Detected63
Low Voltage Disconnect Card64
Figure 47 - Parameters Screen - LVD64
Table 17 - LVD Settings64
View Logs65
Figure 48 - Data Chart for a Week65
Troubleshooting66
Status Warnings66
Table 18 - Status Warnings66
Message Errors67
General Troubleshooting67
Table 19 - Message Errors67
Table 20 - General Troubleshooting67
