Ver-Mac 2016 V-Touch Controller User Manual, V3.0 17
6.3.2 Create a Message Triggered by an IO Device
You must always create a message page to display when all IOs are Off,
even if that page is blank.
Figure 8 - Page Conditions – No IOs active
When there is one IO you must create a minimum of two message pages:
a message to display when the IO is Off.
a message to display when the IO is On.
For more than one IO, the minimum number of associated message pages
increases exponentially.
Example: for two IOs you must have a minimum of four messages:
a message to display when IO#1 and IO#2 are both Off
a message to display when IO#1 is On and IO#2 is Off
a message to display when IO#1 is Off and IO#2 is On
a message to display when IO#1 and IO#2 are both On
You can also have more than one message page linked to the input from an IO.
However they have to be the same page conditions for every single page of the
multi-page message.
Table 6 shows an example of message pages (single page and multi-page
messages) that result from input from two IO detector devices.
