Vertiv Liebert APM2 - Page 33

2. Remove the bottom ratguards, see Figure 3.3 below.
Figure 3.3 Removing Rat Guards
Item Description
1 Rat guard
3. Remove the fixing bolts at bottom of the cabinet as shown in Figure 3.4 below.
Figure 3.4 Removing Bottom Fixing Bolts
Item Description
1 Fixing bolt
3 Mechanical Installation Proprietary and Confidential ©2023 Vertiv Group Corp. 25
Vertiv™ Liebert® APM2 30 to 120 kVA Modular UPS User Manual
