Vertiv™ NetSure™ Control Unit (NCU) User Manual
117
When an EIB and/or SMDU Shunt is Set as Source
See also “Shunts Tab” on page 199.
A “source” icon appears (see Figure 5.7). Clicking on the source icon displays the currents for shunts set as “source” (see Figure 5.8).
Figure 5.7 Source Icon
Figure 5.8 Shunts Set as “Source”
Total of All
Sources
Current
