Vertiv™ NetSure™ Control Unit (NCU) User Manual
Web
Interface Tab
Signal Manual Mode
Authority Level
Required - Web
Authority Level
Required - LCD
HTD Reconnect Point (deg) -- Operator Operator
Time Display Format (format) -- Engineer not available
Temperature Format (C or F) -- Engineer not available
System Alarm Function CR,CR/MJ,CR/MJ/MN) -- Engineer not available
AC Generator Function -- Engineer not available
Manual AC Generator Run -- Engineer not available
AC Generator Start Voltage -- Engineer not available
AC GEN Start Batt Capacity -- Engineer not available
DI for AC Generator -- Engineer not available
Site Has AC Utility Power -- Engineer not available
Settings / Battery Equalize/Float Charge (Float/Equalize) -- Operator Operator
Float Charge Voltage (V) -- Engineer Operator
Equalize Voltage (V) -- Engineer Operator
Number of Battery Shunts (0 to 2) -- Engineer Operator
Batt# Rated Capacity (AHr) -- Engineer Operator
Reset Battery Capacity (Yes) -- Operator Operator
Number of Battery Fuses (0 to 6) -- Operator not available
Calculate Battery Current (yes or no) -- Engineer not available
Temp Comp Sensor (select from list) -- Engineer Operator
Comp Temp High2 (deg) -- Engineer not available
Comp Temp High1 (deg) -- Engineer not available
Comp Temp Low (deg) -- Engineer not available
Temp Comp Center (deg) -- Engineer Operator
Temp Comp Coefficient (mV/deg) -- Engineer Operator
Temp Comp Voltage Clamp (enable/disable) -- Engineer Operator
Temp Comp Max Voltage (V) -- Engineer Operator
Temp Comp Min Voltage (V) -- Engineer Operator
BTRM Temp Sensor (select from list) -- Engineer not available
BTRM Temp High2 (deg) -- Engineer not available
BTRM Temp High1 (deg) -- Engineer not available
BTRM Action (disable/lower voltage) -- Engineer not available
BTRM Voltage (V) -- Engineer not available
Low Capacity Point (%) -- Engineer not available
Curr Limited Mode (yes or no) -- Engineer Operator
Battery Current Limit (# x C10) -- Engineer Operator
Over Current Limit (# x C10) -- Engineer Operator
Automatic Equalize (yes or no) -- Engineer Operator
Equalize Stop Current (# x C10) -- Engineer not available
Equalize Stop Time Delay (min) -- Engineer not available
Maximum Equalize Charge (min) -- Engineer not available
Cyclic Equalize (yes or no) -- Engineer not available
Cyclic Equalize Start Time (date and time) -- Engineer not available
