Chapter 10 File management
Creating a screenshot
102 User Manual 79000000203 Rev. 005
Creating a screenshot
You can create captures of what is displayed on the screen, directly from
the 2000 Platform.
Configuring the parameters of screenshots
To configure the screenshot and choose the format of the generated file:
1 Press H
OME hard key
2 Select the Settings icon to reach the System Settings page.
3 In the Report box, on the line Mode, select Screenshot
Choosing this option, you can save the displayed screen in JPG,
PNG or PDF format, exactly as it is displayed on the screen.
Therefore, if you make a zoom on the trace for example, the file will
only show the zoom section.
4 On the line File format, select if the printed file will be a JPG, PNG or
PDF file.
Taking a screenshot
Once the screenshot parameters are configured:
1 Reach the display which will be saved as a screenshot in a file.
2 If necessary, make modifications on this display (example: zoom on
trace...)
3 Press simultaneously the left and right arrow keys for about 5
seconds
or
Click on the upper banner of the screen and, in the virtual control
buttons bar, press Export key
