Chapter 6 Scope
Launching a test of the connector and fiber end-face
User Manual 79000000203 Rev. 005 61
High mag./Low mag.allows to switch all the images from scope test
results from high to low magnification and vice-versa.
Adding a comment
The key Comment allows you to enter/modify a comment to your picture if
necessary. This comment appears at the bottom left of the picture.
The right bottom of the frozen picture also contains the date of the acquisi-
tion (where the picture was frozen).
Loading a picture
It is possible to retrieve and load a picture stored in the Scope directory and
display it in the Scope page.
1 Press the
FILE button.
2 Press Explorer.
3 Select the JPEG file to be loaded via the Explorer
4 Click on Load
Recognized pictures are images resulting from the Scope option and saved
on disk via the 2000 Platform.
NOTE
Both the comment and the date will be saved with the pic-
ture.
Some pictures resulting from the Scope option may
appear nevertheless unrecognized, if they have been
stored with a different Scope application, or if the JPG
file has been opened and modified under another JPG
editor.
