Chapter 6 Scope
Launching a test of the connector and fiber end-face
60 User Manual 79000000203 Rev. 005
• You may select one of the pictures by clicking on it.
The selected picture is framed in green.
The tool bar on the right varies according to which picture is selected
(camera, or static picture):
Picture selected: Camera
Test Allows to launch a (new) test of the connector (see
“Launching a test of the connector and fiber end-face”
on page 57
)
Freeze The live picture from the camera is frozen but does not
replace the live picture at position 1. The new
snapshot is placed at the second position, and all
existing pictures are pushed to the next position.
High mag./Low mag.allows to modify the live display from high to low
magnification and vice-versa
Picture selected: Image
Comment allows to add a comment to the selected picture (see
“Adding a comment” on page 61)
Save allows to save the selected picture in the directory
Scope, in the disk of the Platfom. Press Save key,
enter a name for the jpg file and validate. This key is
not available with jpg files other than those resulting
from scope application.
Overlay allows to display or hide the limits of each zone and
the defaults on image from a test result (see
“Overlay”
on page 59
).
If all positions were taken, the picture that was once at the
fourth position is unloaded from memory. Frozen pictures
and snapshots are lost, unless they were saved on the
internal memory.
