Chapter 5 Power meter, VFL (Visual Fault Locator) & Talkset
Talkset and Datalink Functions
User Manual 79000000203 Rev. 005 41
Storing results
In order to save the results of a measurement, click on FILE and select
Store trace. Two files are being saved:
• The first file is used with the 2000 Platform and allows to retrieve all
measurement results. It is saved with the extension «.Lts».
• The second file is a ASCII file using tabulations to separate values. It
is saved with the extension «.txt» and can be opened by the 2000
Platform. It has been designed to be used with a spreadsheet
program on a PC where it allows to retrieve all measurement results
and format them in a nice customized table.
Loading results
In order to load the results of a measurement, select a file with the
extension «.Lts» in the file explorer (see the chapter «File management» in
the user manual for «2100 modules series»), click on Load.
The LTS tab is displayed with the loaded results in the table
Talkset and Datalink Functions
The Talkset option enables two operators at opposite ends of an optical
link:
• To communicate along the fiber.
• To transfer data along the fiber.
Each end of the optical link must be provided with a 2000 Platform
equipped with the Talkset option.
