Chapter 6 Scope
File menu
62 User Manual 79000000203 Rev. 005
Even though the JPG editor of the Scope function has been designed to
display Scope pictures in black & white, it is also possible to open any JPG
valid file and display in color the corresponding picture. That picture is
enlarged or shrunk to the size of the display (full screen or mosaic,
see."Mosaic Mode" page 59).
File menu
Saving the test result in a jpg file
Once the test has been performed, and the result is displayed on the 2000
Platform screen:
1 Press F
ILE key
2 Click on Save key to save a jpg file of the test result on the disk of the
2000 Platform.
3 On the edition keypad, enter the name of the jpg file
4 Press Enter to validate.
The file is automatically saved on the disk, in the directory Scope
(icon ).
Generating a report
1 Check the correct test result is selected (framed in green in mosaic
mode).
2 Press the
FILE button, then the Report key
3 On the edition keypad, enter the name of the pdf file and press
ENTER.
The report generation is completed once the icon is no more
displayed on the upper banner.
