Chapter 6 Scope
Configuring the P5000i Scope
User Manual 79000000203 Rev. 005 53
Link Description
The information entered in the Link Description window concerns the
editing and/or the modifications of the cable and fiber parameters.
Cable Id This parameter allows to enter an identification of the
cable, using the Edition menu.
Direction The direction shows if the acquisition has been made
from the origin to the extremity (A->B) or from the
extremity to the origin (B->A). Changing direction
makes it possible, when different extremities are
handled, to see the parameters of the fiber for the
other extremity.
Location A The name of the Location A of the link may be entered.
Location B The name of the Location B of the link may be entered.
Company Enter the name of the company carrying out the test.
Operator Enter the name of the operator carrying out the test.
Press Exit to return to the Results screen of the scope.
Adding a new profile
Once the Setup screen of the scope is displayed, you can add a specific
profile which will be used for the test.
The profile must be created via FiberChek2TM, and stored on one storage
media of the MTS/T-BERD 2000 (disk, or USB memory stick).
1 On the Setup screen, select Profile and press Add key.
NOTE
All parameters of the Link Description box will appear in the
pdf report or jpg file generated from a test results page.
