Chapter 1 2000 Platform Overview
Power Supply
8 User Manual 79000000203 Rev. 005
Power Supply
The 2000 Platform may operate with
• the Li-Polymer battery, already set into the equipment on delivery.
• an AC adapter/charger, via a power cable on which has been set the
correct country adaptable plug.
Charge indicator
Solid green The instrument is connected to an external power source
and the battery is fully charged.
Solid red The instrument is connected to an external power
source, and the battery is on charge.
Testing indicator
Solid red At least one function is in measurement phase (for exam-
ple, the laser emission pilot for an OTDR measurement)
Table 3 Indicators Status
Figure 5 Delivered elements for 2000 Platform supplying
Interchangeable plugs
UK adaptable plug
(installed by default)
EUROPE
adaptable plug
US
adaptable plug
JAPAN
adaptable plug
AUSTRALIA
adaptable plug
Power supply plug
