Chapter 4 Configuring the 2000 Platform
Defining the screen parameters of the 2000 Platform
User Manual 79000000203 Rev. 005 27
Defining the screen parameters of the 2000
Platform
In the System Settings page, the following parameters can be defined:
Backlight
1 Click on Backlight
2 Define the backlight level of the screen, using the left and right direc-
tion keys, or clicking on Edit Number softkey and using the keypad
displayed.
– Min backlight level: -5
– Max backlight level: +5
Contrast
1 Click on Contrast
2 Select the type of environment into which the instrument is used:
– Indoor: to be selected when the instrument is used inside (see
Figure 10 on page 26)
– Outdoor: to be selected in order to optimize the readability of
the screen for an outside use.
NOTE
If you are in the Regional Settings page, and you press
Exit, then the System Settings page automatically dis-
plays.
If the 2000 Platform is operating on battery, it is advis-
able to choose a minimum lighting level, acceptable for
the user, to keep endurance as long as possible.
