31: Configuring Terminal Server
_______________________________________________________________________________________________________
_____________________________________________________________________________________________________
© Virtual Access 2017
GW1000 Series User Manual
Issue: 1.9 Page 292 of 350
Web: Serial Forwarding Timer Mode
UCI: tservd.@port[0]. sfwd_timer_mode
Opt: sfwd_timer_mode
Forwarding timer mode (network to serial).
Idle
Timer is re-started on each received data
Aging
Timer started on the first Rx.
Web: Proxy Mode
UCI: tservd.@port[0]. proxy_mode
Opt: proxy_mode
Defines if special proxy mode is configured to allow ‘hijacking’ of
the terminal server. It allows a connection to be made from a
remote location and redirect terminal server data temporariy for
troubleshooting.
When enabled a TCP proxy server is started which listens for an
incoming TCP connection from a remote peer. Once an incoming
new TCP connection on the proxy server TCP port is accepted:
The existing terminal server TCP client connection is
disconnected.
The terminal server automatically reconnects the TCP client side
but this time to the local loopback address 127.0.0.1 and to the
local proxies TCP port number.
Once the proxy server has both local and remote TCP sessions
connected it simply forwards the data between the two
connections, taking into account the flow control.
When either side TCP socket closes, the main terminal server
client re-connects to the normal IP destination and the server
proxy returns to listening for another connection from the far
end.
0
Disabled.
1
Enabled.
Web: Disable Remote Client’s Local Echo
(Telnet option)
UCI: tservd.@port[0]. disable_echo
Opt: disable_echo
Set to 1 to send IAC WILL ECHO Telnet option to remote client
forcing it to disable local echo. For server mode only.
0
Disabled.
1
Enabled.
Web: Telnet COM Port Control
UCI: tservd.@port[0]. com_port_control
Opt: com_port_control
Set to 1 to enable support for Telnet COM port control
(RFC2217).
0
Disabled.
1
Enabled.
Web: Enable HDLC Pseudowire over UDP
(RFC4618)
UCI: tservd.@port[0]. hdlc_pw_enabled
Opt: hdlc_pw_enabled
Set to 1 to enable HDLC pseudowire over UDP support based on
RFC4618 (requires Transport Mode (udpmode) to be enabled)
0
Disabled.
1
Enabled.
Web: Serial Receive Debug Log Size
UCI: tservd.@port[0]. serialRxLogSize
Opt: serialRxLogSize
Configures serial receive log size in bytes and enables receive
data logging.
0
Disabled.
1
Enabled.
Web: Serial Transmit Debug Log Size
UCI: tservd.@port[0].serialTxLogSize
Opt: serialTxLogSize
Configures serial transmit log size in bytes and enables transmit
data logging.
0
Disabled.
1
Enabled.
Table 102: Information table for port settings section
31.3.2.2 Port settings: serial section
In this section you can configure the serial interface settings, such as port mode, port
speed, parity stip bit and so on.
Note:
 The displayed settings vary depending on options selected.
 DTR <--> DSR signalling is not available on GW2028 router models.
