3-56 BA 901/1101 en – Edition 2.1 * 91101b340.fm
Operation
Lowering the loader unit with the engine stopped
Lower the loader unit as follows:
☞ Ensure that no one is in the danger zone of the machine
☞ Close the safety bars
☞ Turn the starting key to position “1”
☞ Push and hold control lever 20 forward (C),
➥ Until the loader unit is completely lowered
☞ Return control lever 20 to neutral
At engine standstill, or if there is a malfunction in the hydraulic system, the loader
unit can be lowered by means of emergency lowering.
This works only if the safety bar is closed
Fig. 57: Lowering the loader unit with the engine stopped
20
C
