BA 901/1101 en – Edition 2.1 * 91101b610.fm 6-1
Technical data
6 Technical data
6.1 Chassis
Sturdy steel sheet chassis, rubber-mounted engine
6.2 Engine
Engine type
Naturally
aspirated engine
Turbocharged
engine
Model (901sp/1101c/1101cp)
-
•/•/•
Model (901s – up to serial no. DC01239)
• -
Model (901s – from serial no. DC01240)
- •
Product
Deutz diesel engine
Type
D 2011 L04W
TD 2011 L04W
(turbocharged
engine)
Design
Water-cooled 4 stroke diesel engine
Number of cylinders
44
Displacement
3619 cm³ 3619 cm³
Nominal bore and stroke
96 x 125 mm 96 x 125 mm
Output
50 kW
at 2600 rpm
63 kW
at 2500 rpm
Max. torque
200 Nm
at 1700 rpm
270 Nm
at 1600 rpm
Max. engine speed without load
2800 +/− 50 rpm 2700 +/− 50 rpm
Idling speed
1400 +/− 50 rpm 1400 +/− 50 rpm
Specific fuel consumption
239 g/kW-h 238 g/kW-h
Firing order
1-3-4-2 1-3-4-2
Fuel injection system
Direct injection
Starting aid
Preheater (preheating time 10 – 15 sec-
onds)
Max. inclined position
(engine no longer supplied with oil):
30° in all directions
Observe tilting limit (20° lateral) of the
machine!
Diesel tank capacity
70 l
Exhaust values according to
97/68/EC – stage III A
EPA III
ECE-R24
