BA 901/1101 en – Edition 2.1 * 91101b520.fm 5-17
Maintenance
Adding hydraulic oil
Removing the filler plug can cause oil to escape.
Accident hazard!
☞ Carefully unscrew the plug to slowly reduce the pressure inside the reservoir.
Do not add hydraulic oil unless the engine is stopped. Otherwise, hydraulic oil will overflow
at the filler opening on the hydraulic oil reservoir.
☞ Add as follows:
• Park the machine on level ground
• Retract the cylinders of the loader unit, lower the bucket to the ground
• Stop the engine
• Raise the safety bar
• Let the engine cool down
• Slowly open cover C
With the filter insert in place:
• Add hydraulic oil
• Check the hydraulic oil level on sight glass A
• Add if necessary and check again
• Firmly retighten cover C
The cover can be locked with a padlock.
Fig. 104: Hydraulic oil filler inlet
C
